WORDS
PGMTYPE
Program Type
Compiler Options
Purpose
Set the type of program to be compiled.
Syntax
PGMTYPE = MAINPGM/AUTOPGM/FKEYPGM/ERRPGM/CAMPROF
Remarks
The PGMTYPE statement overrides the default compiler option for Program Type set
in the Edit menu, Compiler Options dialog box.
MAINPGM: Normal motion program
AUTOPGM: Auto program, System program zero
FKEYPGM: Fkey program, System programs 1-24
ERRPGM: Error Routine program, System program 27
CAMPROF: Cam profile, requires IQ Cam compiler
This statement requires IQ Master version 3.0 or later.
See Also
DEBUG, COMPILETOMEMORY, LISTFILE, EXPANDMACROS
Example
PGMTYPE = MAINPGM
PGMTYPE = FKEYPGM
PICMD
Current Command, Peak
Current
Purpose
Peak current command in amperes.
Syntax
variable = PICMD
variable
The variable may be a nonvolatile variable Gn, a volatile vari-
able Vn, or a system variable.
Remarks
ICMD is calculated every velocity loop update (1mS). If the current value is greater
than the previous peak, the value is saved as the new peak. The magnitude of the peak
is calculated based on an absolute value of current command (ICMD). The value is
saved and reported as a signed number, however. The variable is scaled by the drive
module current (Dm).
CLRPEAKS resets this value to zero.
See Also
ICMD, CLRPEAKS, IAVE, IAVG
Example
G6 = PICMD
