312

Variables and Flags Assignment and Request Commands • System

Publication 1398-PM601A-EN-P — October 2000

HOST

M

O

D

E

PURGEMOTION

Purge motion queue in the following manner:

Mode bit

Description

0

Normal Pgen

1

Purge Pgen motion queue
immediately. No deceleration of Pgen
to zero velocity performed.

2

Purge Pgen motion from stick queue.
Decelerate Pgen to zero velocity.
Decel rate is the system Accel value.

3

Purge Pgen motion queue
immediately. No deceleration of Pgen
to zero velocity performed.
Normal Pgen motion after purge.

4

Purge Pgen motion from stick queue.
Decelerate Pgen to zero velocity.
Decel rate is the system Accel value.
Normal Pgen motion after purge.

All other values result in Mode 0. Subsequent
moves are ignored until a zero value is assigned.

V

R/W

N

PURGEMOTION-
ACTIVE

TRUE if Motion Purging is complete.

F

R

N

RFDR

Current run time feedrate value in percent.

V

R

N

RLIMIT

Reverse travel limit.

V

R/W

Y

#

ROT

TRUE if counter-clockwise rotation is positive
direction for encoder 1.

F

R/W

Y

ROT2

TRUE if counter-clockwise rotation is positive
direction for encoder 2.

F

R/W

Y

SCALE

Encoder counts per 1 user unit of distance.

V

R/W

Y

#

SCALE2

Encoder 2 counts per 1 user unit of distance.

V

R

Y

#

SEN

TRUE if software enable. (see ENABLE, DIS-
ABLE.)

F

R/W

N

SS

TRUE if program execution in single step mode.
(see STEP.)

F

R/W

N

TBASE

FALSE (0) for velocity in user units per second,
TRUE (1) for velocity in user units per minute.

F

R/W

Y

#

WIN

In-Position window.

V

R/W

Y

#

WINT

In-Position window time.

V

R/W

Y

#

XPLC

TRUE to stop the ULTRA Plus or IQ from exe-
cuting its internal I/O logic. Input status will still
be available but no action will be taken on chang-
ing inputs and outputs will be updated only from
host commands. This command is normally used
only by diagnostics.

F

R/W

N
