Rockwell Automation 1398-PDM-xxx IQ Master Version 3.2.4 for IA-2000 and IQ-5000 Positioning Drive Modules, IQ-55 User Manual
Page 103

Help Menu • Contents
81
Publication 1398-PM601A-EN-P — October 2000
MENUS
Contents
The Contents section contains help on every menu and menu item, and the IQ Basic programming lan-
guage.
How to Use Help
This section provides information on how to use the on-line help.
Context Sensitive Help
Select Context Sensitive Help from the Help menu, press Shift+F1, or click the
(context sensitive
help) toolbar button to obtain help on some portion of IQ Master. The mouse pointer will change to an
arrow and question mark indicating Context Help mode. Click anywhere in the IQ Master window, such
as a Toolbar button or menu item, and the Help topic will be shown for the item you clicked.
About IQ Master
Select About IQ Master from the Help menu or click the
toolbar button to display the version of
IQ Master that you are using. Also displayed in this dialog box is the version of Windows that you are
using and the amount of memory available.
