Wait, Wflag – Rockwell Automation 1398-PDM-xxx IQ Master Version 3.2.4 for IA-2000 and IQ-5000 Positioning Drive Modules, IQ-55 User Manual
Page 301

Language Reference • Reference
279
Publication 1398-PM601A-EN-P — October 2000
WORDS
WAIT
Wait
Program Structure
Purpose
Wait for a condition to occur before proceeding to the next instruction.
Syntax
WAIT condition
condition
The condition to be tested. The condition may be a comparison,
an input being ON or OFF, or a flag being ON or OFF.
Comparisons compare the values of two operands and determine
if the condition is TRUE or FALSE. A comparison may be
greater than (>), less than (<), equal to ( = ), not equal to (<>),
less than or equal to (< = ), or greater than or equal to (> = ). The
operands of a comparison may be user variables, system vari-
ables, analog input values (ADC), or constants.
I1 ON
;an input
F1 ON
;a user flag
INPOSN
;system flag
G1 > G2
;comparison user variable
G1 > POS1
;comparison system variable
POS2 <= 7.00
;comparison constant
Remarks
See Also
DWELL, DELAY
Example
WAIT I12 = ON
WAIT POS1> = G3
WFLAG
Warning Flag
System
Purpose
Flag to indicate if a warning is active.
Syntax
WFLAG= value
value
Value can be ON, OFF, a nonvolatile flag Bn, a volatile flag Fn,
or another system flag.
Remarks
See Also
EFLAG, ENUM, WNUM, SYSERROR, SYSWARN
Example
IF WFLAG = ON º
