Language Reference • Reference
211
Publication 1398-PM601A-EN-P — October 2000
WORDS
Gn
Variable, Nonvolatile, User
Variable
Purpose
Load a user-defined variable with a value from another variable, result of a math
expression, a constant, a timer, or an analog input.
Syntax
Gn = value
variable = Gn
n
The number of the variable. n = 1, 2, 3, ..., 64.
value
Value can be a constant, a nonvolatile variable Gn, a volatile
variable Vn, or a system variable.
variable
The variable may be a nonvolatile variable Gn, a volatile vari-
able Vn, or a system variable
Remarks
G and V variables are stored internally as 4 bytes for the mantissa (the part before the
decimal point), 2 bytes for a numerator (the top part of a fraction), and 2 bytes for a
denominator (the bottom part of a fraction). The range of numbers that can be repre-
sented in 4 bytes is
±
2,147,483,648. The range of numbers that can be represented in 2
bytes is
±
32,767. Therefore, the range of numbers that can be contained in a G or V
variable and any intermediate value is:
The changes made to Gn remain in effect even after power is removed. Changes made
to a Gn by one program will be seen by other programs. Vn variables are volatile and
will lose their values when power is removed
TIP: Variables can be assigned names using the ASSIGN command and then refer-
enced by those names to make the program easier to read.
See Also
Vn, Fn, Bn, Part 4
•
Programming, Arithmetic
Example
G7 = ADC1
G14 = PCMD
G7 = V7 + 1
G8 = TIMER1
G9 = POS1
G or V =
±
+ ±
±
2 147 483 648
32 767
32 767
,
,
,
,
,
