Expansion memory, Using expansion memory, Storing programs in expansion memory – Rockwell Automation 1398-PDM-xxx IQ Master Version 3.2.4 for IA-2000 and IQ-5000 Positioning Drive Modules, IQ-55 User Manual
Page 127: Running programs stored in expansion memory

Expansion Memory • Using Expansion Memory
105
Publication 1398-PM601A-EN-P — October 2000
I/O
Expansion Memory
Additional program memory may be added with the addition of an Memory and I/O Expansion Card.
This board adds 32 Kbytes of addition nonvolatile program memory to the base ULTRA Plus or IQ for
the storage of up to 32 additional programs.
For detail specifications and installation instructions refer to the appropriate ULTRA Plus or IQ-Series
Installation Manual (1398-5.1, Part Number 0013-1027-004 or Part Number 0013-1022-004).
Using Expansion Memory
Storing Programs in Expansion Memory
Programs located in expansion memory appear in a different directory than programs located in the base
ULTRA Plus or IQ. Base ULTRA Plus or IQ programs are in Program Directory 1 and programs in
expansion memory are in Program Directory 2.
Running Programs Stored in Expansion Memory
When using Program Select Lines or Host Language Commands, programs that reside on the Memory
and I/O Expansion Card are referenced by program numbers 32 through 63.
