Language Reference • Reference
223
Publication 1398-PM601A-EN-P — October 2000
WORDS
INPOSN
In-Position
Position
Purpose
In-Position flag. This flag indicates that the feedback position has been within the
In-Position window of the commanded position for the time set by the window time
parameter. This flag is valid during motion and while stopped, but only if the drive is
enabled.
Syntax
variable = INPOSN
variable
The variable may be a nonvolatile flag Bn, a volatile flag Fn, or
another system flag.
Remarks
If the amplifier is disabled, the INPOSN flag will be OFF.
In-Position Mode determines operation of the In-Position flag. If Relative is selected,
the In-Position flag will be activated whenever the system is within the In-Position
Window, even if it is in motion. If Absolute is selected, the In-Position flag will be
turned on only when the system is within the In-Position Window and not in motion
(default setting is Absolute). In-Position mode is set in the Parameter menu, Outputs
dialog box.
If assigned, the INPOSN output (O7) will turn ON when the INPOSN flag is ON and
OFF whenever the flag is OFF.
See Also
WINDOW
Example
F3 = INPOSN
WAIT INPOSN = ON
;Wait until in position.
O1 = ON
;Then turn ON output 1
INT
Integer
Math
Purpose
Strip off any fractional value of Variable_1 and put only the integer part of Variable_2
into Variable_1.
Syntax
Variable_1 = INT Variable_2
Variable_1
The variable_1 may be a nonvolatile variable Gn, a volatile
variable Vn, or a system variable.
Variable_2
Same as Variable_1.
Remarks
If the value to be truncated is negative, the result will be rounded down to the next
lower (more negative) number.
See Also
Gn, Vn
Example
V3 = INT V4
G24 = INT V2
G24 = INT G24
