8-23
Working with Multi-level Containers
containers, as in the following example. In the example, the Type
column indicates two Mirror sets reside on containers 0 and 1.
HPN0> container list
Executing: container list
Cluster Num Total Oth Stripe Scsi Partition
Dr Partner Label Type Size Ctr Size Usage C:ID:L Offset:Size
-- ------- ----- ------ ------ --- ------ ------- ------ -------------
0 0 Mirror 100MB None 2:01:0 64.0KB: 100MB
2:02:0 64.0KB: 100MB
0 1 Mirror 100MB None 2:03:0 64.0KB: 100MB
2:04:0 64.0KB: 100MB
To create a volume set of mirror sets, use the container create
mvolume command, as in the following example. In the example,
containers 0 and 1 are used to create a volume set of mirror sets.
HPN0> container create mvolume 0 1
Executing: container create mvolume 0 1
Container 0 created
After running the container create mvolume command, use
the container list command to display information about the
volume set of mirror sets, as in the following example. In the
example, the Type column indicates a top-level Volume set, whose
container ID is 0, and two underlying Mirror sets, whose container
IDs are 63 and 62. (Containers 63 and 62 are hidden containers.)
These three containers make up the volume set of mirror sets. The
Total Size
column indicates that the volume set of mirror sets is
200MB (megabytes), which is the total size of the two underlying
mirror sets.
HPN0> container list
Executing: container list
Cluster Num Total Oth Stripe Scsi Partition
Dr Partner Label Type Size Ctr Size Usage C:ID:L Offset:Size
-- ------- ----- ------ ------ --- ------ ------- ------ -------------
0 0 Volume 200MB None
0 63 Mirror 100MB 2:01:0 64.0KB: 100MB
2:02:0 64.0KB: 100MB
0 62 Mirror 100MB 2:03:0 64.0KB: 100MB
2:04:0 64.0KB: 100MB
