Brocade Virtual ADX MIB Reference (Supporting ADX v03.1.00) - Manual (Page 119)

Brocade Virtual ADX MIB Reference 107
53-1003312-01
VLAN by protocol configuration table
VLAN by protocol configuration table
The following table applies to protocol VLANs.
snVLanByPortCfgStpDesign
atedRoot
brcdIp.1.1.3.2.7.1.19
Syntax: BridgeId Read only Shows the dot1dStpDesignatedRoot, which is the bridge identifier of
the root of the spanning tree as determined by the Spanning Tree
Protocol as executed by this node. This value is used as the root
identifier parameter in all configuration bridge PDUs originated by this
node.
(Refer to RFC1493 Bridge MIB.)
snVLanByPortCfgBaseBridg
eAddress
brcdIp.1.1.3.2.7.1.20
Syntax: MAC address Read only Shows the MAC address used by this bridge when it must be referred
to in a unique fashion. It is recommended that this be the numerically
smallest MAC address of all ports that belong to this bridge, however,
it is only required to be unique. When concatenated with
dot1dStpPriority a unique bridge identifier is formed which is used in
the Spanning Tree Protocol.
snVLanByPortCfgVLanNam
e
brcdIp.1.1.3.2.7.1.21
Syntax: DisplayString Read-write Shows the name of the VLAN community string.
Valid values: Up to 32 characters.
snVLanByPortCfgRouterIntf
brcdIp.1.1.3.2.7.1.22
Syntax: Integer32 Read-write This object is optional. It identifies the virtual interface for the router to
the VLAN, and applies only to the router. If an SNMP-Get value is zero,
that means this object was not configured.
snVLanByPortCfgRowStatus
brcdIp.1.1.3.2.7.1.23
Syntax: Integer Read-write Determines whether or not the VLAN will be deleted:
•
other(1)
•
valid(2)
•
delete(3)
snVLanByPortCfgStpVersion
brcdIp.1.1.3.2.7.1.24
Syntax: Integer Read-write Shows the version of Spanning Tree Protocol the bridge is currently
running.
•
stpCompatible(0) – STP (IEEE 802.1D)
•
rstp(2) – RSTP (IEEE 802.1w)
Name, OID, and Syntax Access Description
Name, OID, and Syntax Access Description
snVLanByProtocolTable
brcdIp.1.1.3.2.2 None The VLAN by Protocol Configuration Table.
snVLanByProtocolEntry
brcdIp.1.1.3.2.2.1 None An entry in the VLAN By Protocol Configuration Table.
snVLanByProtocolVLanId
brcdIp.1.1.3.2.2.1.1 Read only Shows the VLAN ID index to both the VLAN By Port Info Table and this
table.
