2.2.12 Trace Properties
Select File > Trace Properties to see the properties of the trace. For more information refer
to
“Trace Properties” on page 117 .
2.2.13 Edit Comment
You can write comments and edit them for a trace for future use. Select File > Edit Comment
to view the edit window. Key in the comments and close the window.
2.2.14 Projects
You can define a new project, starting with the default project definition, or modify the
settings for the last project run.
New Default Project
To start a New project, select File > New on the main menu bar and choose SAS
Protocol Analyzer or SATA Protocol Analyzer to open a new project with default settings
that you can modify (see
“Main Window” on page 43 ).
Last Project
Clicking the Green button opens the last project run, so you can modify it.
Project File Types
Projects have the following file types:
*.asl Decoding script file (in the Examples folder “User Define Decoding Script”
subfolder)
*.cfg Display Configuration file (in the System folder “Config” subfolder)
*.dat DataBlock file (in the System folder “DataBlock” subfolder)
*.sac SAS Protocol Analyzer/Capture Project/Viewer file (in the Examples folder
“EasyCaptr”, “AdvanceCaptr”, or “Exerciser” subfolders)
*.saf Device Identifier file
*.scs SAS Sample file (in the SAS Examples folder “Sample” subfolder)
*.sfl Filter configuration file
*.spg Single‐role Pattern Generator file (in the Examples folder
SAS “PatternGenerator\Single role (spg files)” subfolder and
SATA “PatternGenerator\Single Role” subfolder). Single role means the file is for
a Device or Host.
*.ssh SAS Search configuration File
*.stc SATA Protocol Analyzer/Capture Project/Viewer file (in the Examples folder
“EasyCaptr”, “AdvanceCaptr”, or “Exerciser” subfolders)
