Teledyne LeCroy Sierra Trainer Generation Language
344 Sierra M124 SAS/SATA Protocol Analyzer User Manual
Predefined Constants
Generation Settings
Predefined Constant Internal Value
GEN_MODE_ERROR 0
GEN_MODE_SATA_HOST 1
GEN_MODE_SATA_DEVICE 2
GEN_MODE_SAS_INITIATOR 3
GEN_MODE_SAS_TARGET 4
GEN_LINK_SPEED_1_5G 00
GEN_LINK_SPEED_3G 01
GEN_LINK_SPEED_6G 10
SCRAMBLING_MODE_NONE 0
SCRAMBLING_MODE_SAS 1
SCRAMBLING_MODE_SATA 2
Setting
Default
Value
Description
Global Settings
GenerationMode
>>>>> Generation Mode ‐ must be defined or no generation
will take place. Possible Values:
GEN_MODE_SATA_HOST GEN_MODE_SATA_DEVICE
GEN_MODE_SAS_INITIATOR
GEN_MODE_SAS_TARGET
Default Value: GEN_MODE_ERROR ‐ undefined mode
SSCEnable 0 Spread Spectrum Clocking (SSC)
In SATA software, turns SSC on or off. Can only be set
outside Generation block.
In SAS software, when you turn on SSC, Trainer PHY
can turn on SSC on the PHY. In the SAS protocol,
during speed negotiation, when both sides of a link
agree to turn on their SSC, SSC will turn on, with the
SSC Type and SSC Amplitude parameters.
SSCType Specifies SSC type as midspread.
