Sierra M124 SAS/SATA Protocol Analyzer User Manual 327
Sierra Trainer Generation Language Teledyne LeCroy
Power_Expansion_On(n)
Power_Expansion_Off(n)
Switch on power expansion card. The Default
value is POWER_SOURCE_5V |
POWER_SOURCE_12V. The power source can be
combination of POWER_SOURCE_1_2V,
POWER_SOURCE_1_5V, POWER_SOURCE_3_3V,
POWER_SOURCE_5V, POWER_SOURCE_12V
Switch off power expansion card. The Default
value is POWER_SOURCE_5V |
POWER_SOURCE_12V.The power source can be
combination of POWER_SOURCE_1_2V ,
POWER_SOURCE_1_5V ,
POWER_SOURCE_3_3V, POWER_SOURCE_5V,
POWER_SOURCE_12V
Exit (ExitCode) Call this command in any branch of the Trainer
program to stop execution. After exit, the
Port Status dialog displays the exit code.
Note: The Trainer GUI has LED
indicators:
Green is for pass.
Red is for fail.
No color is for unknown or for
user to review.
set_trainer_interconnect_signal_1 or
settrainerinterconnectsignal_1 Set these signals to allow other ports to wait on
them using
WF_TRAINER_INTERCONNECT_SIGNAL_1
set_trainer_interconnect_signal_2 or
settrainerinterconnectsignal_2 Set these signals to allow other ports to wait on
them using
WF_TRAINER_INTERCONNECT_SIGNAL_2
set_trainer_interconnect_signal_3 or
settrainerinterconnectsignal_3 Set these signals to allow other ports to wait on
them using
WF_TRAINER_INTERCONNECT_SIGNAL_3
set_trainer_interconnect_signal_4 or
settrainerinterconnectsignal_4 Set these signals to allow other ports to wait on
them using
WF_TRAINER_INTERCONNECT_SIGNAL_4
SET_EXTERNAL_TRIGGER Call this command to set External Trigger Out
Settings and External Trigger In Type to High
Active, Low Active, Toggle and set External
TrigOut pulse width.
SET_ANALYZER_TRIGGER Call this command to set Analyzer Trigger.
