Teledyne LeCroy Analysis
118 Sierra M124 SAS/SATA Protocol Analyzer User Manual
Figure 3.3: Trace Properties Dialog
3.3 Analysis
The Analysis menu options allows you to see the trace in various views and switch views.
3.3.1 Show Analysis Toolbar
To display the capture in any of the other available views you can make the selection on
the View Type toolbar as shown below or select the menu option under Analysis as
shown in
Figure 3.5 on page 119 .
Figure 3.4: View Type Toolbar
Compare 2 Data
Show Hide Fr. Inspector View
Show/Hide Statistical Report View
Show/Hide Packet View
Show/Hide Spreadsheet View
Show/Hide Column View
Show/Hide
Decoding Assignments
Show/Hide Text View
Show/Hide Bus
Data Report
Running
Show/Hide Histogram View
Waveform View
Utilization View
Payloads
Verification Scripts
