Sierra M124 SAS/SATA Protocol Analyzer User Manual 299
Starting the Script Editor Teledyne LeCroy
Pop-up Menu
Left‐click anywhere in the script window to open a pop‐up menu with the following
options:
 Display Options: Selects what information to display. See “Display Options” on
page 366 .
 Edit as Text: Opens the Script Editor.
 Zoom In: Increases the size of the displayed elements
 Zoom Out: Decreases the size of the displayed elements
 Wrap: Wraps displayed packets within the window.
 Compact: Displays each row on one line only, with no wrapping
File Tabs
At the bottom of the window is a tab that shows the name of the .ssg file. If your .ssg file
has an Include statement in it, the supporting Include files automatically open when the
.ssg file is first opened. Tabs for the opened Include files appear at the bottom of this
window.
Figure 5.14: File Tab
Error Log
Whenever you create a scripting error, a log opens at the bottom of the application
window. When the error is corrected, the window automatically closes.
Figure 5.15: Log
Tooltips
The Script Editor window includes extensive tooltips for each keyword. To see a tooltip,
hold the mouse pointer over a keyword.
