Sierra M124 SAS/SATA Protocol Analyzer User Manual 47
SAS/SATA Software Menus and Toolbars Teledyne LeCroy
2.2 SAS/SATA Software Menus and Toolbars
The SAS and SATA software has the following menus and toolbars.
2.2.1 SAS Main Toolbar
The following figure displays the SAS main toolbar.
Figure 2.3: SAS: Software Menus and Toolbar
2.2.2 SATA Main Toolbar
The following figure displays the SATA main toolbar.
Figure 2.4: SATA: Software Menus and Toolbar
Open Project File
Launch Trainer
Launch Jammer
Abort Capturing Without Saving Sample File
Start Target Emulator
Find DUT
Stop Recording
Upload Manager
Start Recording
Stop Target Emulator
Save
Manual Trigger
Open Project File
Launch Trainer
Launch Jammer
Abort Capturing Without Saving Sample File
Start Device Emulator
Find DUT
Stop Recording
Upload Manager
Start Recording
Stop Device Emulator
Save
Manual Trigger
