Sierra Trainer Generation Language
Teledyne LeCroy
SSCAmplitude
Specifies SSC Amplitude. Possible values are:
SSC_AMP_500
SSC_AMP_1000
SSC_AMP_1500
SSC_AMP_2000
SSC_AMP_2500
SSC_AMP_3000
MultiSpeedMode
0
When set, the change of speed within Generation
block is allowed with following syntax: set Speed =
LINK_SPEED_1_5G / LINK_SPEED_3G /
LINK_SPEED_6G
Output Disable
0
This very poorly named register bit forces the Trainer
to output data. It is a little like the output_on script
command except that its effect cannot be undone for
the duration of the script. If this is turned on, none of
the out‐of‐band commands will work, as the output
enable is forced on.
SupportSNW1
1
When set, in “Connect command” SNW1 will be tried
in Speed Negotiation phase
Can only be set outside Generation block.
SupportSNW2
1
When set, in “Connect command” SNW2 will be tried
in Speed Negotiation phase.
Can only be set outside Generation block.
PauseTrnScrmblr.
0
When set, the generator pauses the Idle scrambler of
Train/TrainDone pattern.
ReconnectOnRun
0
When “AdvanceConnect” and “ReconnectOnRun”
are set, the “Connect” command forces the Trainer
to disconnect the physical link before executing the
“Connect” command.
When “AdvanceConnect” is not set, this setting does
not affect the Trainer.
AdvanceConnect
0
When set, the Trainer uses the
“PHY Capability” and “SupportSNW” settings,
instead of the “Set Speed” settings, for executing the
“Connect” command.
OutputOffAfterDC
On
Off
If set to On, Trainer puts DC Idle on line when it
detects sync lost on the link.
Setting
Default
Value
Description
