Sierra M124 SAS/SATA Protocol Analyzer User Manual
213
Floating License
Teledyne LeCroy
Two port configuration (AA ‐ ‐): If trigger is set at 50%, but there is not
enough data to fill pre‐trigger, Memory Assignment has an effect. Sample
size is typically more than half specified size, with size determined by the
amount of data captured before trigger.
Note:
Checking this option does not affect the sample. It only allows larger sample sizes.
Note:
If traffic is balanced on ports, sample size is the same whether you check or uncheck the
Sampling Memory Usage Optimization option.
Note:
Memory Assignment depends on traffic load distribution at the time when the system tries to
re‐assign physical links to memory banks. Therefore, if you repeat a capture with the same
Sampling Memory Size and Segment Number parameters, the resulting sample size may not be
the same. However, if traffic load distribution is similar, sample size will be similar.
Note:
The buffer status indicator shows buffer by FPGA, not by port.
If the Sampling Memory Usage Optimization Option is Not Checked
Each physical link (or logical link if MUX is enabled) is assigned to a specific memory space
(memory bank), depending on the Sampling Memory Size and Segment Number
parameters.
Important: If any physical link fills its memory bank, the recording process stops. Other
memory banks will typically be less than full (and can be empty). The sample file might be
smaller than the user‐defined Sampling Memory Size. You might even think that the
Analyzer malfunctioned.
3.17 Floating
License
Note:
License Manager is only available when in Cascading mode. For example, if one unit is licensed
only for JJJJ and a second unit is licensed only for AAAA, cascading the two units and using the
License Manager allows each unit to do JJAA.
To manage the license, select Setup > Manage Setup Licenses.
The Floating License dialog (see
) displays the available
functionality by Function, Total Ports, Assigned To ports, and Not Used. It also displays the
Current License Configuration by License Type, Serial Number, Analyzer, Device Emulator,
Host Emulator, and InFusion.
Note:
Sierra M124 currently does not support Device Emulator, Host Emulator, and InFusion.
