Teledyne LeCroy Scenario Events
240 Sierra M124 SAS/SATA Protocol Analyzer User Manual
TABLE 4.2: Events
Event Description
Address Frame Occurrence of a specified address frame.
Analyzer Trigger Trigger on Analyzer when its event matches. You can see the
trigger on the Status Bar, but the Port Status dialog does not
display any mark in the Trigger column.
Note: This is different than the external trigger mechanism.
You do not need an external trigger cable.
Note: The Trigger on Analyzer feature functions when the
trigger pattern is set to "Pattern/Infusion" and running a
scenario which will trigger analyzer after a 5s timer. A
message "Triggered, Post‐Trig Capturing" displays on the
Software Status bar.
Note: When the analyzer triggers, it triggers on a packet
before the actual trigger event occurs. The trace triggers
more than 1us before the event actually occurs. The trigger is
on the Initator side instead of the Target side as set in the
scenario.
Any DWORD Occurrence of any DWORD.
ATA Command Occurrence of a particular ATA command.
ATA Command Frame Occurrence of a particular ATA command frame.
[+] ATAPI Occurrence of a particular ATAPI command from the list:
MMC4, RBC, SBC2, SMC2, SPC2, SPC3, or SSC2.
Both Links Up Occurrence of both line ports active (not idling).
CRC Error Occurrence of a CRC error.
DWORD Matcher Occurrence of a particular DWORD.
FIS Frame Occurrence of a particular FIS frame.
FIS Type Occurrence of a particular SATA FIS type.
Frame Type Occurrence of a particular frame type.
Invalid 10bit‐code
Error Occurrence of an invalid 10b code.
Links Speed 3G Both lines operating at 3 Gbps.
Links Speed 6G Both lines operating at 6 Gbps.
Links Speed 12G Both lines operating at 12 Gbps.
OOB Signal Occurrence of OOB signal.
[+] Primitives Occurrence of Primitive Group, SAS Primitive, or SATA
Primitive.
Running Disparity Error Occurrence of Running Disparity (RD) error.
SAS Data Pattern
Occurrence of a particular data pattern in a SAS frame.
SATA Data Pattern Occurrence of a particular data pattern in a SATA frame.
{+} SCSI Occurrence of a particular SCSI command from the list:
MMC4, RBC, SBC2, SMC2, SPC2, SPC3, or SSC2.
SMP Frame Occurrence of a particular SMP frame.
