Sierra M124 SAS/SATA Protocol Analyzer User Manual 329
Sierra Trainer Generation Language Teledyne LeCroy
LRT: Last received TTIU This instruction is for accessing the last received
TTIU. The user can access the received TTIU and
reuse it as required.
Example:
{
@ttiu_mask=0x0006000
@ttiu=LRT
@ttiu_temp=@ttiu and @ttiu_mask
If(ttiu_temp=0006000)
{
Send_ttiu(0x0006000)
}
}
Training_ERROR_COUNT This instruction is for accessing the error count
of the received Dwords. This gives flexibility to
the user to change the remote tx parameters to
get the optimal link with minimal errors.
Example:
Var32 @error_count
Generation
{
Send_ttiu ((0x00006000, 0x36, 0xA)
Wait_ttiu (change_ttiu , 0x00004000)
@error_count= Training_ERROR_COUNT;
If(@error_count<2)
{
Send_ttiu ((0x0000A000, 0x36, 0xA)
}
}
