Sierra M124 SAS/SATA Protocol Analyzer User Manual 301
Generating Traffic Teledyne LeCroy
For any available Link, you can select any open script from the Script drop‐down list.
After you select an open script, you can assign or remove a link for that script by clicking
Assign Active Script/Remove Assigned Script for Link.
5.10 Generating Traffic
After the .ssg file has been opened onscreen, recording and traffic generation can begin
at any time.
1. (optional) Click to begin the recording.
2. If the script does not have a connect block built into it, connect the exerciser to the
DUT by clicking the Connect Link button . Clicking this button causes the
generator to invoke the various settings in your script (for example, the global
settings) and then establish a connection.
