EVS MULTICAM - User’s Manual Version 8.03
EVS Broadcast Equipment SA – Dec 2006
62
Using the EVS Remote Panel.
HOW TO DEFINE A CLIP?
1. Select the LIVE mode
2. Use the JOG knob to go in search mode and define your SHORT IN or
SHORT OUT point.
3. Press the IN key to mark your SHORT IN point of the clip.
4. Search for the desired SHORT OUT point and then press the OUT key
to mark it.
A clip can be created with only IN point or only OUT point. The system
will automatically give a duration to the clip according to the default
duration defined in the Setup menu.
Note : you can mark an in or out point on a paused record train and go
back to live without losing the point marked by pressing Shift+Return.
HOW TO STORE A CLIP?
1. Define a clip by marking IN and/or OUT points.
2. Select the clip page (PAGE 1 contains clips 110 to 199, PAGE 2
contains clip 210 to 299, and so on) by pressing SHIFT + PAGE
3. Then select the BANK where the clip will be stored by pressing SHIFT
+ F_ keys. i.e. Bank n°3 press SHIFT + F3
Bank n°7 press SHIFT + F7
4. Now select the location of the clip to store and press the
corresponding F key.
i.e. clip n°112 SHIFT + F1 (to select bank n°1) then F2
(to select location n°2).
!
Important note : The AUTO-SAVE process automatically saves clips and playlists
at least every minute. With Multicam 5.03.25 or higher, playlists are included in
the AUTO-SAVE process. Exiting the software (ALT+Q) or doing “Save Clips+Plist”
from the main menu will also save the clips and playlists.
HOW TO RECALL A CLIP?
1. Select the CLIP PAGE 1, 2, 3, … to 10 (PAGE key).
2. Select the BANK in which the desired CLIP is located
3. Choose the desired CLIP (F1 - F10).
If PREF is ON, the preferred camera angle of the clip will appear on the
primary channel, the secondary camera angle on the next controlled
channel, then the other camera angles on the next channels in
alphabetical order. Ex : if the preferred camera angle for clip 124 is
