4. SETUP

Important Note: Prior to using the MULTICAM, the operator should enter the

SETUP menu and set all necessary parameters. If clips are stored with certain
parameters and the operator wishes to change them afterwards, those clips and
playlists will not change. Thus, it is important to set these parameters first.

The SET-UP menu allows the operator to define parameters regarding
some functions. The new parameters are saved as soon as they are
modified.

HOW TO ACCESS THE SET-UP MENU?

Press SHIFT+ MENU key to return to the MAIN menu

S p l i t P a i n t T a r g e t

S e t u p

1 P G M + P R V

2 / 3 P G M

And then press SETUP (SHIFT + D) to enter the SETUP menu.

The setup is divided in sections : clips, playlists, special effects, audio,
control, GPI, etc. When entering the setup, a menu presents these
sections. Each section can be accessed directly by pressing the
corresponding F_ key. Inside a section, F9 and F10 are used to move to
the previous/next page. When the first/last page of a section is reached,
the next F9/F10 goes to the last/first page of the previous/next section,
so that by starting on the first page and pressing F10, the operator goes
through all pages : p.1.1 Æ p.2.1 Æ p.2.2 Æ…

LSM Setup Menu Main page

[F1]OSD Settings [F6]EVS Controller

[F2]Record Trains [F7]RS422 Control

[F3]Clips [F8]GPI

[F4]Playlist [F9]Special Effects

[F5]Audio Clr+[F0]Restore Defaults

[Menu]Quit [Clr+F_]Default [F0]PgDn

Inside a section, pressing Menu key brings the operator back to the main
menu of the setup. On this page, pressing Menu key exits the setup.
Pressing CLEAR + the corresponding Function key will reset the default
value for the selected section (confirmation required). Pressing CLEAR +
F0 will reset the entire setup menu to the default values (confirmation

If you are in PLAYLIST mode, press RECORD first to exit this mode, then SHIFT+MENU to go the Main Menu.
