EVS MULTICAM - User’s Manual
EVS Broadcast Equipment SA – Dec 2006
Version 8.03
137
15. Paint
Mode
Note: The Paint Mode is a software option.
This option is not available in HD configuration.
The facilities within this software package can be operated using the
tablet and the stylus, or a touch screen. Selected in the SETUP, the
normal pointing device is the tablet, selecting F2 - page 6.2 will toggle
between tablet / touch screen (only when the touch screen is available).
The touch screen must always be connected to the RS422 port #6 and
defined on page 7.2 (F6) of the Setup.
The use of the LOOP function allows the operator record the effect back
into the 1
s t record channel of the server, and to create a clip with the
paint feature. Rolling a clip while in the LOOP mode, in Painting, and
dissolving paint image on/off allows for a very powerful feature.
STRAIGHT LINE / BROKEN LINE DRAWING
Select L, you will be prompted to enter the first point of the line.
Place the pen at the start point and press lightly. Then place the pen at
the next point and press lightly again. A straight line appears to connect
these 2 points. Repeat this as many times until the line is complete, then
place the pen over the “ESC” area in the top right corner of the OSD and
press lightly. The system automatically defaults back to freehand
drawing mode.
CIRCLE DRAWING (LARGE OR SMALL)
Select either C or c, you will be prompted to select the position of the
center of the circle.
Place the pen on the tablet at the point where the center of the circle
must be located. The circle will appear. The system automatically defaults
back to freehand drawing mode.
ARROW
Select A. When you draw on the tablet and remove the pen, a «neat»
arrow appears at the end of the line. This facility remains «on». When no
longer required, select A again.
COLOR & DENSITY
Select D. Choose the desired color from the display, then choose the
desired thickness.
This will be stored as Br1 or Br2 depending on which one is currently
selected when entering the ‘D’ option. Thus, two types can be stored.
