EVS MULTICAM - User’s Manual
EVS Broadcast Equipment SA – Dec 2006
Version 8.03
11
TRANSPORT CONTROLS
JOG DIAL
The JOG DIAL allows the operator to pass into SEARCH mode and thus to
choose exactly the SHORT OUT or SHORT IN image. Move the JOG DIAL
clockwise to search forward and move it counter-clockwise to search
backwards. One revolution of the JOG DIAL will produce a jump of
approximately 35 frames. This number can be multiplied by enabling the
FAST mode. The multiplication factor is defined in the SETUP menu.
Note : The JOG DIAL is also used :
- to set parameters in the SETUP menu. Refer to the SETUP menu section for more
information.
- To BROWSE inside the clips database, the cue points or the current playlist. Refer to
the explanation of the BROWSE function for more details.
The JOG dial is active at all times when the system is in PLAY & RECORD
LEVER
The LEVER is used to start a play or to modify slow motion speed. Its
run can be of two different types regarding the lever mode.
Normal run:
In this mode, the LEVER run goes from 0 up to 100%.
Second range:
The second range is available to play material from –100% to 100% or
from –200 to 200% with a larger step at 0% (see SETUP menu - page 5-
F4 for selection)
To gain access to this second speed range, press SHIFT + LEVER from
the remote controller.
Note that when SD SUPER MOTION material is loaded on the primary
channel, the lever range as a larger, flat step at 33%. With HD SUPER
MOTION, the step is at 33% or 50% depending on the camera.
The lever is also used to adjust speed, and effects type and duration in
Playlist Edit mode.
