EVS MULTICAM - User’s Manual Version 8.03
EVS Broadcast Equipment SA – Dec 2006
108
the location where the clip must be inserted. Call the selected clip, it
appears on the PRV output . Press INSERT or TAKE to insert it in the
playlist at the position shown on PGM output. A confirmation message
will appear if that option has been enabled in the setup menu.
If no PRV output is available, the clip will appear on the PGM output. Use
the INSERT key (SHIFT+BROWSE) to insert the clip into the playlist then
press PLST to return to the playlist at the current position.
Note: Depending on what is selected in the SETUP menu, the clip will be inserted before
or after this selected position.
!
Important note: In PLST EDIT mode with a PRV channel, when PRV CTL is
enabled, the operator as full control of the PRV channel while the playlist remains
loaded on the PGM channel. On the PRV channel, he can perform all clip-related
functions, including database search using time code, keywords and ranking, from
the VGA Search Screen as well as from the secondary clip menu of the remote
panel. Once the desired clip(s) are found, they can easily be inserted in the playlist
that is still loaded on the PGM output. By switching PRV CTRL ON or OFF, the
operator can very easily combine playlist editing and database search functions.
HOW TO MERGE PLAYLISTS?
From the VGA, it is possible to merge two playlists by copying a playlist
and pasting it to an existing playlist. The copied playlist will be added at
the end of the destination playlist.
HOW TO TRIM CLIPS INTO A PLAYLIST?
Every clip inside a playlist can be trimmed independently of all other
instances of the same clip number.
1. Browse to the desired clip in the playlist
2. Re-mark a new SHORT IN or SHORT OUT, or if the clip duration is
too short, clear the IN or OUT point by selecting CLEAR and then
the desired IN or OUT point.
Note: Clearing restores the existing IN or OUT point to the end of the guardbands of the
clip.
THE AUXILIARY AUDIO CLIP
The Aux Clip option allows you to add a new stereo audio track to the
original video clips. For example: sport comments, music, jingles, ambient
sound… This additional stereo audio track is available on the PVW
output and on analogue outputs 7/8 or on digital outputs 15/16. The
selection of the track output is done via the SETUP menu – Page 5.1 -
F5. The original audio tracks are still available on outputs 1/2 (3/4). The
auxiliary audio clip selected is always played back with normal speed
(100%), whatever the selected playback speed for the video.
