Second Lever Range:
The T-Bar lever can be used in normal mode: to play back clips at slow
motion speed from 0 to 100%. Or secondary range is available to
playback material at the following speeds :
-100% 100%
0 200%
-200% 200%
0 400%
-400% 400%
To gain access to the secondary speed from the remote controller, press
SHIFT + LEVER/TAKE.
Default: –100% to +100%
The second lever range is also available when editing the speed of
playlist clips.
Recall clip toggle:
(Enable/Disable)
This option allows the operator to select the camera of a clip through the
Function keys. Pressing several times the F key browses to CAM A, CAM
B, CAM C, CAM D, CAM E and CAM F.
Default: Enable
EVS Controller p.6.2
[F1]Record key : Start REC + Live
[F2]Pointing device : Tablet
[F3]VGA & RMT Sync : No
[F4]PGM/PRV Mode : Enable
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
Record Key:
(Live / Start REC+Live)
This parameter changes the function of the RECORD key on the remote.
Start REC+Live: Hitting the RECORD key starts the RECORD process and
switches to LIVE mode.
Live: hitting the RECORD key only switches to last recorded picture, but
the record is not restarted if it has been previously stopped by the
operator.
Default: Start REC+Live
Pointing Device:
(Tablet / Touch Screen)
Initializes the Tablet or the Touch Screen. If the tablet is not properly
calibrated, use this function to re-initialize it. If using the Touch Screen,
this one must always be connected to RS422 port #6 of the XT, and
defined as such at page 7.1 of the setup.
Default: Tablet
