Defines the Xfile where clips must be sent when using the ARCHIVE
function from the EVS remote panel or VGA screens.
Default : -------- #--

Grab image:
Default : disabled.
When the function is enabled and a default x-file has been assigned, the
grab function is coupled with the ‘mark’ key on the remote. Each time the
‘Mark’ key is used, a cue point is marked and a command is sent to the x-
file to save that image.
The grab can also be activated on the keyboard with the combination :
‘ctrl + G’.

Browse button : Browse/Sort-TC
Default : Browse
Allows the user to convert the function of the Browse button. In the
default Browse mode, it will activate the Playlist Browse directly. If the
assignment is changed to SORT-TC, the system will perform a SORT-TC
directly. The system will not prompt the user with a select menu, and it
will use the current TC on the channel to search with the last selected
criteria.

If the user wants to perform a search with different criteria (Search Net or
Local, StartDate, EndDate, CAM/CLIP, etc… ) the user should use the
normal Sort-TC selection in the upper menu.

Reset Archive Status:
Pressing F6 will resets the archive status of all clips present on the
system. Confirmation required. Refer to the description of the ARCHIVE
function for details.

Timeline p.3.4

[F1]TL Receive Pg: 1 2 3 4 5 6 7 8 9

[F2]Mono per Track : 1

[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn

Receive Page:
Default : 0
Selects where clips that are created as part of the timeline editing
process will be stored.

Mono Per Track
The timeline edit feature still has only two audio tracks for editing, but we
will allow more than one mono to be assigned to each audio track.

For instance, if you are working in 4 tracks, you can assign the first
stereo pair to audio track 1 and the second to audio track 2.

The parameter on page 3.4, F2 : mono per track is used in the following
way :
Possible values :
