Note: When a clip/playlist is loaded on a channel, switching back to Live mode will recall
the record train, which was last used on that output. This avoids too frequent uses of
the RST CAM function.
Sync To: This button allows you to synchronize the selected PGM in use
with another one. Press this button and then select the PGM to be used
as a reference. This function is not available with network trains.
Toggle / All:
Toggle OFF: Selecting an output channel results in control of that channel
and disables the control on others.
Toggle ON : Selecting a channel will alternatively enable/disable the
control over that channel without changing the control on the others.
All: Selects control of all channels.
Note: The TOGGLE function is only available in 3PGM mode.
2nd CTRL: allows the operator to swap the control of one or several play
channels between the EVS remote and a third-party controller using the
Sony BVW75 or XtenDD35 protocol. Both controllers receive the status
of the channel(s) all the time, but only one controller at a time is able to
actually control a channel. The secondary controllers are defined in
section 7 of the remote Setup Menu.
Press this function to enter the 2nd CTRL menu, select the channels that
you want to pass to the secondary controller by pressing the
corresponding A, B or C key, then press D (DONE) to validate your
selection. Do the same to bring the control of a channel back to the EVS
remote.
Selecting a camera on a channel: select first the channel where you
want to change the current camera. You can notice that the TAKE key at
the bottom of the remote lights RED. If you press the TAKE key now, it
lights GREEN and the menu on the LCD display changes to let you select
the desired camera. To return to the PGM selection menu, press the
TAKE key again.
Note: The 1PGM mode is a simplified version of the 2 or 3PGM modes. The operational
menu has less functions :
L o c a l 2 n d C T R L
C a m A C a m B C a m C C a m D
Also, the user does not need to select a channel to enable or disable the secondary
controller. Since there is only 1 channel available in this mode, the operator just has
to press SHIFT + D to swap the control between the secondary controller and the
EVS remote.
