EVS
MULTICAM - User’s Manual
Version 8.03
EVS Broadcast Equipment SA – Dec 2006
32
Special Control Settings p.7.2
Main RS422 Second. RS422
PGM1: EVS Remote -- [F5]Sony BVW75 04
PGM2:[F2]EVS Remote –- [F6]Sony BVW75 05
PGM3:[F3]EVS Remote –- [F7]---------- --
PGM4:[F4]EVS Remote –- [F8]---------- --
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
This page is used to define which device/controller can control which
PGM channel. For each PGM channel, you must define the main
controller, selecting from the list defined on page 7.1.
- In LSM mode, the main controller for PGM1 must always be an EVS
remote. This can not be changed by the operator.
- If the main controller is an EVS remote, the RS422 port will be
automatically assigned and is not specified by the operator.
- If the main controller is an EVS remote, it is then possible to specify a
secondary controller for that channel, that can be either a Sony
BVW75, XtenDD35 or Odetics protocol defined on page 7.1. The EVS
remote controlling that channel can then decide at any time to pass
the control to, or to retrieve the control from the secondary controller.
- Like for page 7.1, all EVS remotes must be the first in the list of Main
controllers, without gap. It is not allowed to have a protocol
preceding an EVS remote in this list.
- A protocol (other than EVS AVSP protocol) can only be assigned to 1
channel at a time.
- EVS AVSP protocol can be assigned to several channel
simultaneously. If you need to assign some channels to an Air Box,
you must set the main controller for these channels to EVS AVSP.
Main Controller for PGM1:
(EVS Remote)
When working in LSM base configuration, PGM1 main controller must
always be an EVS remote. No other possible selection
Main Controller for PGM2/3/4:
(EVS Remote + list of protocols-RS422 ports defined on page 7.1)
Default : EVS Remote
Secondary Controller for PGM1/2/3/4:
(list of Sony BVW75, XtenDD35 and Odetics protocols defined on page
7.1)
Available only if the main controller for that channel is an EVS remote.
Default for PGM1 : Sony BVW75 on RS422 #4
Default for PGM2 : Sony BVW75 on RS422 #5
Default for PGM3 & 4 : ---------- --
