EVS MULTICAM - User’s Manual Version 8.03
EVS Broadcast Equipment SA – Dec 2006
132
5. Type the desired name on the keyboard.
6. Press F1 to name the remote clip.
→ in CAM mode, only the camera where the cursor is located is named
→ in CLIP mode, all cameras of the clip where the cursor is located
are named.
Note: To be able to rename a clip on a remote server, the parameter “Clip edit by
network” must be enabled in the Setup Menu.
HOW TO MODIFY IN/OUT POINTS OF A REMOTE CLIP?
Recall the desired clip, browse inside the clip until you reach the desired
frame, press IN / OUT to mark a new SHORT IN / SHORT OUT point.
Note: To be able to trim a clip on a remote server, the parameter “Clip edit by
network” must be enabled in the Setup Menu of the remote machine.
HOW TO INSERT REMOTE CLIPS INTO A PLAYLIST?
1. Select the REMOTE LSM via the Network menu.
2. Then select a remote clip in the banks. The corresponding F-key
lights red.
3. Press ENTER on the Remote.
4. Repeat the 3 first points as necessary until last clip is entered.
in Playlist mode, the remote display gives all needed information
regarding this playlist and this information is updated each time a clip is
stored in the playlist.
HOW TO ROLL A PLAYLIST WITH REMOTE CLIPS?
1. Once the playlist is cued and ready to roll, select the playlist from
P L 1 1 L S M 0 1 M I C H E L L O C T D U R = 0 0 : 0 0 : 5 8 : 2 2
1 5 2 A / 0 3 C l i p
0 1 1 2 0 0 : 0 1 : 2 0 U n k W 0 0 : 1 0
1 1 1 A / 0 4 C l i p F o o t 0 0 : 1 0 : 2 5 U n k W 0 0 : 1 0
1 1 2 B C l i p n a m e 4 5 6 7 0 0 : 0 4 : 2 9 U n k W 0 0 : 1 0
1 1 2 B / 0 2 C l i p 0 1 1 3 0 0 : 0 1 : 1 0 U n k W 0 0 : 1 0
5 5 2 C / 0 8 n o n a m e 0 1 2 3 4 0 0 : 0 2 : 5 0 U n k W 0 0 : 1 0
C l r U n a v . E F F E C T E D I T A L L
I N S E R T S P E E D D U R E F D E L E T E
