EVS MULTICAM - User’s Manual Version 8.03
EVS Broadcast Equipment SA – Dec 2006
16
required).
HOW TO SELECT AND TO MODIFY PARAMETERS?
Adjustments are made as follows for most parameters :
ƒ Once you’ve reached the desired page, choose the parameter to
be modified by pressing the corresponding Function key & make
adjustment by rotating the JOG knob, then press the
corresponding Function key again.
ƒ To restore the default value of a parameter, press CLEAR and the
corresponding Function key.
ƒ To return to the main page of the SETUP menu, press MENU
OSD Settings p.1.1
[F1]Genlock Error Msg : Yes
[F2]Disk Error Msg : Yes
[F3]Network Error Msg : Yes
[F4]Cue number on OSD : Yes
[F5]Keyword info : No
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
Genlock Error Msg:
(Yes / No)
Enables or disables the Genlock information on the monitoring output. If
Genlock reference is not correct, the !GkV message appears on the
monitoring output.
Default : Yes
Disk Error Msg:
(Yes / No)
This function displays an error message (!Dsk) on the output monitor
when a disk is faulty.
Default: Yes
Note: The LSM-XT is equipped with a RAID disk array. This means that the operation can
continue seamlessly even with 1 faulty disk. If 1 disk is disconnected during
operation, the “!Dsk” message appears on all monitoring outputs, and another
message appears when the operator shuts down the application, to invite him to
replace the disk and rebuild the RAID array.
Refer to the Technical Reference manual for details on the RAID system and its
maintenance.
Network Error Msg:
(Yes / No)
This function displays an error message (!Net) on the output monitor
when the network connection is faulty and another message (ÆNet) when
the network becomes available again and the system is trying to re-
connect.
Default: Yes
Cue number on OSD:
(Yes / No)
When set to “Yes”, the cue number is displayed on the OSD of the
monitoring outputs when a cue point is recalled inside a record train.
