EVS MULTICAM - User’s Manual
EVS Broadcast Equipment SA – Dec 2006
Version 8.03
111
HOW TO SET DEFAULT VIDEO AND AUDIO TRANSITIONS?
The simplest type of Split Audio edit that can be performed on an LSM is
to make the Video and Audio Transitions at the beginning of the clip have
different Durations, such as a 12 Frame Video Mix with a 2 sec Audio
crossfade.
A default value for each can be entered in the Setup Menu so that each
time a clip is entered or inserted into a playlist the Default values are
used.
Vid. Effect duration is on page 4.1, function key F1 (range up to 20:00
secs)
Aud. Effect duration is on page 4.1, function key F2 (range “Lock to
video”, then up to 20:00secs)
!
Important note: If the “Audio Effect Duration” parameter in the setup is set to “Lock
to video”, it will never be possible to adjust independently the duration of the audio
and video transitions. If you want to adjust one of these transitions and the other one
follows, please check the “Audio Effect Duration” in the setup, and make sure it is
NOT set to “Lock to Video”.
In an LSM playlist the Video and Audio effects end at the out point of a
clip, so the duration of clips is shortened by the length of the effect.
Normal Playlist with Cuts
Playlist with 1:00 sec Effect Duration
