EVS MULTICAM - User’s Manual Version 8.03
EVS Broadcast Equipment SA – Dec 2006
28
EVS Controller p.6.1
[F1]Effect duration for Take : 00s05fr
[F2]Fast jog : 20x
[F3]PGM Speed/Var Max : 50%
[F4]Lever engage mode : Direct
[F5]Second lever range : -100% <-> +100%
[F6]Recall clip Toggle : Enable
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
Effect Duration for Take:
(00s00fr to 20s00fr)
Defines the duration of the transition when using the TAKE key to chain 2
sequences in PGM+PRV mode.
Default: 00s05fr
Fast Jog:
(01 to 20 times)
sets the increment of the jump when in Fast Jog mode.
Default: 20x
Pgm Speed/Var Max:
(1 – 100%)
during playback, if PGM Spd or VarMax has been enabled in the
secondary menu of the remote, the lever range will be adapted so that :
- the only playback value for any position of the lever other than 0, is
the one specified by this parameter in the setup (PGM Spd mode ON),
- or the speed range defined by the lever is limited to the value
specified by this parameter (VarMax mode ON).
Default: 050%
Lever Engage mode:
(Direct / Current speed)
The speed variation depends on the position of the T-Bar lever.
Direct mode: the lever will engage directly when moved, resulting in a
speed jump to the desired speed determined by the lever arm position.
Current speed mode: the lever will only engage when it reaches the
current playback speed, whereas a move of the lever arm in the opposite
direction of the current speed will result in a direct speed change.
Default: Direct
