EVS MULTICAM - User’s Manual Version 8.03
EVS Broadcast Equipment SA – Dec 2006
120
Display on the OSD
*PL11/03* LEFT 06:42:22
V Mix 02:25 Spd.Unk
A Mix*02:25 A.Del. 00:00
IN-00:00:00 OUT+00:00:27
LOOP
12:23:45:13 00:07:13 100
112B/04 ClipName 999/999
USING THE SWAP AUDIO TRACK MODE IN MANUAL MODE
If the manual mode is selected in the setup menu, page 4.2, function key
F3, the swap functions in a similar way but asks the operator which track
to swap when setting the swap points.
First the operator is being asked :
In 2 Tracks mode : “Select original track : 1 2 or Menu to Cancel”.
In 4 Tracks mode : “Select original track : 1 2 3 4 or Menu to Cancel”.
In 8 Tracks mode : “Select original track : 1 2 3 4 5 6 7 8 or Menu to
Cancel”.
The functions keys are used to select the track to change.
When the choice is made, the operator selects by which track the
selected one has to be replaced :
In 2 Tracks mode : “Select new track : 1 2 0”.
In 4 Tracks mode : “Select new track : 1 2 3 4 0”
In 8 Tracks mode : “Select new track : 1 2 3 4 5 6 7 8 0”
Note : Selecting track 0 will mute the output until the next swap point or
the end of the clip.
Several swap points can be set on the same timecode (e.g. : 1 -> 3, 2 ->
4).
DELETING SWAP POINTS
If the operator is on a swap point, pressing ‘CLEAR’ + ‘IN/OUT’ deletes
the current swap point. All swap points for that timecode are deleted.
If the operator is not on a swap point, pressing ‘CLEAR’ + ‘IN/OUT’ brings
up a confirmation message to delete all swap points for the current clip.
NAVIGATING SWAP POINTS
When the operator is in swap mode, the previous swap point can be
reached by pressing the Go to In button on the remote. The next swap
point is reached by pressing the Go to Out button. The function works in
loop mode.
