VGA & RMT Sync :
(No, Yes, Server Nbr)
Select whether and how the current clips machine, page and bank of VGA
screens and EVS remote panel must be synchronized.
- “No” : clips machine, page and bank can be selected independently on

the VGA screen and on the EVS remote panel ;

- “Yes” : clips machine, page and bank are synchronized between VGA

screen and EVS remote panel. Connecting to the clips of a network
machine or coming back to the clips of the local machine, or selecting
a new page or bank on one side will be automatically reflected on the
other ;

- “Server Nbr” : clips pages and banks can be selected independently

on VGA and remote, but connecting to the clips of a network machine
or coming back to the clips of the local machine on the VGA or remote
panel will automatically reflect on the other.

Default : No

PGM/PRV Mode
Default : Enable
Allows the user to disable the PGM/PRV mode from appearing on the
remote’s main menu ([A] Button).

Mapping network cam p.6.3

[F1]Authorize cam mapping : Yes

Cam A

: Local

Cam B

: Local

[F3]Cam C

: CamA/01

[F4]Cam D

: CamB/01

[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn

Note : This is a software option.
Allows to map network trains to unsued local camera position up to
camera D. If the camera is local (cam A and B on the example), no F keys
are assigned to it. If the position can be used by a network camera, the F
key is available. Select a cam position and jog with the dial to reach the
desired network camera to map.
Refer to the corresponding section is the SDTI network chapter for more
information.

Port Device/Protocol p.7.1

RS422 #1 EVS Remote [F7]ID Type:

[F2]RS422 #2 EVS Remote ID LSM

[F3]RS422 #3 EVS Remote

[F4]RS422 #4 Sony BVW75

[F5]RS422 #5 Sony BVW75

[F6]RS422 #6 Touch Screen

[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn

This page is used to define what type of device/controller is connected to
each RS422 port of the XT.

RS422 #1:
