or the speed defined in the setup (p.6.1 F3) for any other position of
the lever.
- VAR MAX mode : the speed range defined by the lever is limited
between 0% and the speed value defined in the setup (p.6.1 F3).
Sw To In: If enabled (highlighted) a camera change will cause a jump to
the corresponding IN point if existing. It will switch in sync if no IN point
exists for the current element, or if SW to IN is OFF.
Pref: Selecting this function enables the Preference mode.
Aud.Met.: Enable/Disable the display of audio meters for all channels
using the OSD of the monitoring outputs.
PostRoll: When the POST ROLL mode is enabled, that function is
highlighted on the LCD and a “P” appears on the OSD of the monitoring
outputs. When playing a clip, it will not stop on the OUT point, but will
continue to play through the OUT point by the Post Roll duration defined
in the Setup Menu. It will do the same inside a record train if the “Record
Train OUTs” parameter is set to “Freeze” in the Setup Menu. When
playing a playlist, the Post Roll will apply only to the last clip of the
playlist.
Sort->TC: This function allows the operator to search for all clips that
contain a particular time code. When calling this function, the time code
of the current picture is used as a default selection. The operator can
immediately perform the search or he can edit that time code before
starting the search. The search is performed on local clips only if
confirmed with SHIFT+ENTER or on the entire XNet SDTI network if
confirmed with ENTER. If matching clips are found, the remote will
automatically be in BROWSE mode (the BROWSE key is red), allowing
the operator to quickly view the frame of each clip corresponding to the
requested time code by rotating the jog dial. To be able to jog inside a
clip, disable the BROWSE mode by pressing on the BROWSE key and
move the jog dial. To return to the BROWSE mode inside the search
results, press the BROWSE key again.
Search results are reset when going by to LIVE mode, or when a new
search is performed.
Practical examples :
- You have loaded the picture of an interesting event, and you want to
see all clips that contain that same event. Call the SORT->TC
function and confirm with ENTER (network search) or SHIFT+ENTER
(local search). Move the jog dial and you will see the same event on
the same time code from all available camera angles that have been
clipped.
- You know the time code of a particular event and you want to see all
clips containing that event. Call the SORT->TC function, edit the time
code to the desired value and press ENTER or SHIFT+ENTER and you
will obtain the same result as above.
Search: This function allows the operator to search the database using
keywords and ranking. Refer to the “Keywords Management” section of
this manual for further details.
