CDM-625 Advanced Satellite Modem Revision 15
Front Panel Operation MN-CDM625
5–88
► Data Rate when configured for Header Compression
► Data Rate when configured for Payload Compression
► Symbol Rate when configured for IP-ACM
► Open Network Framing
► Modulation:
 8PSK/8-QAM
 16-QAM
► Drop & Insert:
 1-port D&I
 4-port (Quad) D&
► L-Band
► IP-ACM (Adaptive Coding Modulation)
► 25 Mbps Header Compression
► 25 Mbps Payload Compression
► G.703 Clock Extension
► Advanced QoS (Quality of Service)
► AES Encryption
► Fractional CnC (DoubleTalk Carrier-in-Carrier)
► Advanced Network Timing (PTP – Precision Timing Protocol)
5.2.8.1.2 FAST: Options  Set Registers
Appendix C. FAST ACTIVATION PROCEDURE
FAST: Set register#: Enter code below
88888888888888888888 then [ENTER] ()
Where ‘#’ is the appropriate register #1, #2, or #3: FAST: Options  Set Registers is used to
enable new options in the modem on a per-register basis. It is important to use the appropriate
FAST access code for the appropriate register.
Contact a Comtech EF Data sales representative, during normal business hours or via e-mail to
[email protected] , to order the desired options (see Sect. 5.2.7.1.1) – be prepared to
provide the Modem Serial Number. The Comtech EF Data Customer Support representative will
