Chapter 3 - Product application Setup
60
three additional softkeys are displayed on the right side of the screen. they allow
the operator to toggle between the data screens without leaving the arm Setup
menus. the All Settings softkey displays the options available (the main screen).
the ARM Files softkey displays the options pertaining to file storage information
(record, guideline, map, boundary files, and collection interval). The Application
Settings softkey displays the options pertaining to the application setup (Swath
manager, system delay, speed source, and gSo speed).
Table 3-4: ARM Setup
Item
description
Record File (.RCd)
Spray trajectory data for product application is stored in record files. They contain rate,
spray on/off data, boom width, and data entered in the Job Report.
guideline File (.gLN)
Contains all information required to view and re-use the guidelines created and used
during product application.
map File (.gmF)
Used to store field features that may be needed during application.
Boundary File (.BNd)
Used to show existing or create new field boundaries.
Collection interval
How often data is collected and written to files.
Rate Lookahead
the time aRm must look ahead of the vehicle to change variable application rates.
Swath manager
autoboom shut off and the technique used to stop application over previously-applied
areas (off, Boom 50%, Boom 100%, 0%, 50%, and 100%).
off Lookahead
the time Swath manager must look ahead of the vehicle to stop application.
on Lookahead
the time Swath manager must look ahead of the vehicle to start application.
System delay
delay used before product is applied.
Speed Source
Source of ground speed (radar or gPS). if using a wheel pick up sensor, select “radar”
as the speed source.
gSo Speed
ground Speed override (gSo) is the minimum speed used for automatic application
rate control. when the vehicle speed falls below this setting, the gSo speed is used to
control the application rate, rather than the actual ground speed.
All Settings
softkey (F8)
ARM Files
softkey (F9)
All Settings
softkey (F8)
