Chapter 2 - System overview 26
Table 2:6 - Pre-Created Channel Favorites
name description
gRaNdC-a Defines a granular application in Split-Drive with three monitors.
gRaNPwm-a Defines a granular application using a PWM valve.
gRaNSeRVo-a Defines a granular application using a Servo valve with one monitor (shaft).
gRaNSeRVo-B Defines a granular application using a Servo valve with no monitor.
iNJ-a Defines an injection application.
LiQFLow-a Defines a liquid application using a flow meter with one monitor.
SPiNmotoR-a Defines a shaft sensor used to control spinner speed.
application type
the Application Type Setup page allows for the selection of the required type of
product application. all other setup pages are based on the type of application
chosen on this page. There are five possible application types:
Liquid
•
granular
•
Seeder
•
Nh3
•
motor
•
For each application type there is an additional Settings page. to access the Set-
tings page, press the Settings softkey on the Application page (refer to table 2-7).
if there are no changes required, press the Forward Arrow softkey to advance to
the next Channel Setup page.
when changing application type, the Finish Flag softkey may disappear. this but-
ton disappears if the change in application type caused additional changes to other
Channel setup parameters. it may be necessary to continue viewing the remain-
ing setup parameters prior to finishing the channel setup process. If no additional
Channel parameter changes occurred, the Finish Flag softkey will be displayed.
Pressing the Finish Flag softkey will activate the final Setup page. From the Finish
page, update the channel with the new setup file.
Settings softkey
(F2)
Forward Arrow
softkey (F6)
Finish Flag
softkey (F7)
