Polygon-mark. map or locate features represented by a closed shape comprised
of discrete points. Press to mark points along the polygon perimeter. a prompt will
request an object name.
Polygon-Stream. map or locate features represented by a closed shape made up of
streaming points. Press to turn streaming oN and oFF. a prompt will request an object
name.
mark Boundary Polygon - maps the perimeter and obtains the area of a feature by a
closed shape comprised of discrete points. Saved as a boundary file (.BND) and used
in an aRm application as the Boundary File.
Streamed Boundary Polygon - used to map the perimeter and obtain the area of a
feature by a closed shape comprised of streaming points. Saved as a boundary file
(.BNd) and used in an aRm application as the Boundary File.
maPPeR oPtioNS
the View Options softkey is located on the Map page. Pressing the View Options
softkey launches a menu on the Map page. the options menu contains mapping
aides and tools that can be used without exiting the mapper process. all items on
the Options menu are toggle-type. the items are either set to “oN” or “oFF”. to
activate an option, use the Arrow keys to select the appropriate item and press the
Enter button. Pressing the Enter button will switch the state of the option item (if the
item was oN, it will be switched oFF).
Figure 6-12: Options Menu
View Options
softkey
Arrow keys
Enter button
