Chapter 2 - System overview 18
Table 2-2: System Setup Components
Component description
Allows the activation of FieldPilot assisted steering and fine-tune settings.
Defines system variables such as units, language, date, and time.
Defines lightbar settings and lightbar messages.
Allows the Legacy 6000 to be configured to match the GPS receiver.
Defines vehicle or implement parameters including width, number of swaths,
number of boom sections and width of boom sections.
Configures each Channel that is connected to the system and turned on.
Console Setup
Console Setup defines system environment settings (units, language, time) used
in rate control and guidance applications. Settings that can be modified are located
in the center column.
Figure 2-13: Console Setup Page
Console Setup
softkey
