Figure 3-6: Typical Calibration Process
Product Calibration Sequence
distance Calibration Sequence
PRime iNJeCtioN SyStem
The priming feature appears as an option only if “Injection” was selected as
the “drive Type” during Channel setup. Priming the system takes chemicals
from the supply tank directly to the injection point to ensure the chemicals are
injected instantly at the start of application.
Select Calibration mode Quick Full
enter Calibration #
Calibration Complete
Reported distance
known distance
Reported vs. known
distance
Calibrated distance
Select Calibration type
Select Calibration mode in-Field Static
View discharged material
in dCm
enter known amount of
material
apply Calibration
accept Calibration
enter application Rate
enter material density
enter Vehicle Speed
discharge material
