Chapter 2 - System overview 32
Table 2-12: Units of Measurement
settings description u.s. metric
Liquid area
distance
time
gal/ac, gal/1000ft2,
gal/100yd2, l/ac
gal/lmi
gal/min
l/ha, l/100m2
l/lkm (liters per lane km)
kg/ha, kg/100m2, t/ha
granular area
distance
time
lb/ac, lb/1000ft2,
lb/100yd2, tn/ac, kg/ac
lb/mi, lb/lmi, tn/lmi, tn/mi
lb/min, tn/h
kg/ha, kg/100m2, t/ha
kg/lkm, kg,km, t/lkm
kg/min, t/h
Seeder area 100 sds/ac, 100 tb/ac 100 sds/ha, 100 tb/ha
Nh3 area lb/ac kg/ha
motor time rpm rpm
injection area
distance
time
fl oz/ac, fl oz/1000 ft2, fl
oz/100 yd2, l/ac
fl oz/lmi
fl oz/min
l/ha, l/100 m2
l/lkm (liters per lane km)
l/min
Primary Sensor
the Primary Sensor is used for principal control functions and is based on the type
of applications selected. each Primary Sensor type has an associated Settings
softkey that launches the Sensor Settings page.
each Channel has six available input sensors labeled a through F. Sensor inputs
a through d are digital (frequency) and sensor inputs e and F are analog. the
sensor input lines on the dCm Product harness are labeled a through F. the input
lines may be set for a sensor on the Sensor Settings page.
Figure 2-27: Primary Sensor Page
Settings softkey
(F2)
