Drive Installation 2-43
7000 “A” Frame 7000A-UM150F-EN-P – June 2013
Cable Insulation
The cable insulation requirements for the PowerFlex 7000 “A”
Frame drive are given in the tables below.
A T T E N T I O N A T T E N T I O N Voltage ratings shown in the following
tables are peak line-to-ground. Some cable
manufacturers rate voltage line-to-line RMS.
Ensure the cable meets the rating specified
in the following tables.
Cable Insulation Requirements for 6P / PWM Drives with Line Reactor
System Voltage (V, RMS)
Cable Insulation Rating (kV)
(Maximum Peak Line-to-Ground)
Line Side Machine Side
2400  2.2  4.1
3000  2.75  5.12
3300  3.0  5.63
4160  3.8  7.1
6000  5.5  10.8
6300  5.8  11.4
6600  6.0  11.8
Cable Insulation Requirements for 18P and 6P / PWM Drives with Isolation
Transformer
System Voltage (V, RMS)
Cable Insulation Rating (kV)
(Maximum Peak Line-to-Ground)
Line Side Machine Side
2400  4.1  2.2
3000  5.12  2.75
3300  5.63  3.0
4160  7.1  3.8
6000  10.8  5.5
6300  11.4  5.8
6600  11.8  6.0
Cable Insulation Requirements for “Direct-to-Drive” Technology
System Voltage (V, RMS)
Cable Insulation Rating (kV)
(Maximum Peak Line-to-Ground)
Line Side Machine Side
2400  2.2  2.2
3000  2.75  2.75
3300  3.0  3.0
4160  3.8  3.8
6000  5.5  5.5
6300  5.8  5.8
6600  6.0  6.0
