Transient suppression network – tsn (cont.) – Rockwell Automation 7000A PowerFlex Medium Voltage Drive (A-Frame) - Classic Control User Manual
Page 316
6-12
Component Definition and Maintenance
7000A-UM150F-EN-P –June 2013
7000 “A” Frame
W
V
U
Line Terminals from
Drive Input Power
Transient Suppression Network
Medium Voltage Input Fuses
Phase MOV
Suppressor
Ground MOV
Suppressor
W
V
U
Line Terminals from
Drive Input Power
Transient Suppression Network
Medium Voltage Input Fuses
Phase MOV
Suppressor
Ground MOV
Suppressor
Figure 6.10 – Simplified Wiring Diagram (2400/3300/4160 V)
U
V
W
Line Terminals from
Drive Input Power
Transient Suppression Network
Medium Voltage Input Fuses
Phase MOV
Suppressor
Ground MOV
Suppressor
Phase MOV
Suppressor
U
V
W
Line Terminals from
Drive Input Power
Transient Suppression Network
Medium Voltage Input Fuses
Phase MOV
Suppressor
Ground MOV
Suppressor
Ground MOV
Suppressor
Phase MOV
Suppressor
Figure 6.11 – Simplified Wiring Diagram (6600 V)
Transient Suppression
Network – TSN (cont.)
