Converter cabinet components – Rockwell Automation 7000A PowerFlex Medium Voltage Drive (A-Frame) - Classic Control User Manual
Page 311
Component Definition and Maintenance 6-7
7000 “A” Frame
7000A-UM150F-EN-P –June 2013
Converter Cabinet Components
Isolated Gate Drive
Power Supplies
(IGDPS)
Rectifier Modules
Voltage Feedback Boards
Transient Suppression
Network Fuses
Transient
Suppression
Network
Inverter Modules
Isolated Gate Drive
Power Supplies
(IGDPS)
Rectifier Modules
Voltage Feedback Boards
Transient Suppression
Network Fuses
Transient
Suppression
Network
Inverter Modules
Figure 6.7 – Converter Cabinet Components (3300/4160 V version)
Note: For 2400V version, refer to page 4-48.
For 6600V version, refer to page 4-50.
