A-2
Catalog Number Explanation – Drive Selection
7000A-UM150F-EN-P – June 2013
7000 “A” Frame
Table A-2
Service Duty Rating, Continuous Current Rating and Altitude Rating Code
Service Duty Rating and Altitude Rating Code
Continuous Current Capability
Code
Rating
A = Normal Duty
0-1000 m Altitude (@ 40°C ambient)
B = Normal Duty
1001-5000 m Altitude
(2000 m Altitude @ 37.5°C ambient)
(3000 m Altitude @ 35.0°C ambient)
(4000 m Altitude @ 32.5°C ambient)
(5000 m Altitude @ 30.0°C ambient)
C = Heavy Duty, 0-1000 m Altitude
(maximum 40°C ambient)
D = Heavy Duty
1001-5000 m Altitude
(2000 m Altitude @ 37.5°C ambient)
(3000 m Altitude @ 35.0°C ambient)
(4000 m Altitude @ 32.5°C ambient)
(5000 m Altitude @ 30.0°C ambient)
40
40 Amp.
46
46 Amp.
53
53 Amp.
61
61 Amp.
70
70 Amp.
81
81 Amp.
93
93 Amp.
105
105 Amp.
120
120 Amp.
140
140 Amp.
160
160 Amp.
Z =
Custom Configuration
(Contact Factory)
Table A-3
Supply Voltage, Control Voltage, Frequency and Control Power Transformer Selection
Voltage
Frequency
(Hz)
Modification Number
Nominal
Line
Control
With a
C.P.T.
Without a
C.P.T.
2400
120
60
A
AD
120-240
AA
—
3300
110
50
CY
CDY
220
CP
CDP
4160
110
50
EY
EDY
220
EP
EDP
120
60
E
ED
120-240
EA
—
6600
110
50
JY
JDY
220
JP
JDP
110-220
JAY
—
A Control Power Transformer modification must be selected (6, 6B ...etc.) to size the transformer.
Control Circuit Power is supplied from a separate/external source. Terminal blocks shall be provided to accommodate.
