Rockwell Automation 7000A PowerFlex Medium Voltage Drive (A-Frame) - Classic Control User Manual
Page 371
Component Definition and Maintenance 6-67
7000 “A” Frame
7000A-UM150F-EN-P –June 2013
When replacing with a new filter, the filter must be provided by Rockwell
Automation or approved for use by Rockwell Automation. Replacement
of the filters is performed in the reverse order of its removal. Check that
there are no openings that would allow foreign matter to enter the drive.
Retaining Hardware
Filter
Retaining Hardware
Filter
Figure 6.51 – Filter Replacement
