Operator Interface

7000A-UM150F-EN-P – June 2013

7000 “A” Frame


2. Position the card vertically so the key slot is facing the right side

of the operator interface.

KEY SLOT


3. Insert the card into the card slot and push until the card is firmly

seated.

W A R N I N G

W A R N I N G

Do not force the card into the slot. Forcing the
card into the slot may damage the connector
pins.
