Rockwell Automation 7000A PowerFlex Medium Voltage Drive (A-Frame) - Classic Control User Manual
Page 78
2-38
Drive Installation
7000A-UM150F-EN-P – June 2013
7000 “A” Frame
Line Cable
Terminations
Fan Power
Transformer
Assembly
AC Line Reactor
Motor Cable
Terminations
Low Voltage
Compartment
Current
Transformers
Hall Effect Sensors
Line Cable
Terminations
Fan Power
Transformer
Assembly
AC Line Reactor
Motor Cable
Terminations
Low Voltage
Compartment
Current
Transformers
Hall Effect Sensors
Figure 2.14 – Cabling Cabinet with Integral Line Reactor, Without Input Starter
